LOADER MODEL

Standard Bucket Size [in]

54

Maximum Lift Height [in]

82.7

Dig Depth [in]

2.6

Lift Capacity to Full Height at Pivot Pin [lbs]

1402

Breakout Force [lbs]

2690

Shipping Weight [lbs}

627

ENGINE

Type

Four-stroke, Natually Aspirated, Indirect Injection, Water Cooled Diesel Engine, Coplies with US TIER-4 Final Norms

Engine HP {kW} @ RPM

25 (19.3) @ 2500

Displacement [in3 (cc)]

80.4 (1318)

Number of Cylinders

3

Fuel Tank [gal (L)]

6.1 (23)

DRIVE TRAIN

Transmission

HST - 2 Ranges

Number of Speeds

Infinite

Clutch

Dry-Single

Brakes

Wet Disc

PTO

Type

Live

Rear PTO RPM

540 @ 2376

Mid PTO RPM

2000 (Opt.) @ 2526

PTO HP (kW)

20.2 (15)

HYDRAULICS

Type

Open Center

Implement Pump Output [gpm (L/min)]

5.8 (22.1)

Maximum Total Flow [gpm (L/min)]

8.5 (32.2)

3-Point Hitch

CAT I

Lift Capacity [lb (kg)]

2315 (1050)

ELECTRICAL

Battery

12 V, 450 CCA

Alternator

12 V, 50 A

DIMENSIONS

Overall Length [in (mm)]

110 (2795)

Overall Width [in (mm)]

54.3 (1380)

Overall Height [in (mm)]

84.3 (2140)

Wheelbase [in (mm)]

63.2 (1605)

Minimum Ground Clearance [in (mm)]

11.4 (290)

Turning Radius [ft (m)]

7.2 (2.2)

Weight [lb (kg)]

1973 (895)

WHEELS & TIRES

AG [Front/Rear]

7-12 / 9.5-16

IND [Front/Rear]

23 x 8.50-12 / 12-16.5

TURF [Front/Rear]

23 x 8.5-12 / 33 x 12.5-15
