LOADER MODEL

25LSK

Standard Bucket Size [in]

50

Maximum Lift Height [in]

75.3

Dig Depth [in]

4.1

Lift Capacity to Full Height at Pivot Pin [lbs]

900

Breakout Force [lbs]

2000

Shipping Weight [lbs}

549

ENGINE

Type

Four-stroke, Natually Aspirated, iNDirect Injection, Water Cooled Diesel Engine with US TIER-4 Final Norms

Engine HP {kW} @ RPM

24 (18) @ 2600

Displacement [in³ (cc)]

71.7 (1175)

Number of Cylinders

3

Fuel Tank [gal (L)]

5.8 (22)

Bore & Stroke [in]

3.07 x 3.23

DRIVE TRAIN

Transmission

HST - 2 Ranges

Number of Speeds

Infinite

Clutch

Dry-Single

Brakes

Wet Disc

PTO

Type

Independent

Rear PTO RPM

540 @ 2550

Mid PTO RPM

2000 @ 2550

PTO HP (kW)

14.9 (11.1)

HYDRAULICS

Type

Open Center

Implement Pump Output [gpm (L/min)]

4.5 (17.0)

Maximum Total Flow [gpm (L/min)]

7.1 (26.9)

3-Point Hitch

CAT I Narrow with Check Chains

Lift Capacity [lb (kg)]

1323 (600)

ELECTRICAL

Battery

12 V, 450 CCA

Alternator

12 V, 50 A

DIMENSIONS

Overall Length [in (mm)]

100.5 (2552)

Overall Width [in (mm)]

45.8 (1164)

Overall Height [in (mm)]

91.3 (2320)

Wheelbase [in (mm)]

57.5 (1460)

Minimum Ground Clearance [in (mm)]

9.4 (240)

Turning Radius [ft (m)]

7.2 (2.1)

Weight [lb (kg)]

1638 (742)

WHEELS & TIRES

AG [Front/Rear]

6 x 12 / 9.5 x 16

IND [Front/Rear]

20 x 18-10 / 27 x 12.5-12

TURF [Front/Rear]

20 x 8-10 / 29 x 12.5-15
