ENGINE

Type

Four-stroke, Naturally Aspirated, Direct Injection, Water Cooled Diesel Engine

Engine HP {kW} @ RPM

45 @ 2300

Displacement [in³ (cc)]

166.2 (2723)

Number of Cylinders

4

Fuel Tank [gal (L)]

17.1 (64.7)

DRIVE TRAIN

Transmission

Full Synchro Mesh with Forward/Reverse Sychro Shuttle & Constant Mesh Range

Number of Speeds

12F/12R

Clutch

Dual Dry with Cerametallic Lining

Brakes

Fully-enclosed, 7-inch Diameter, Dry Disc

PTO

Type

Independent

Rear PTO RPM

540 @ 2300 / 540E @ 1725

Mid PTO RPM

N/A

PTO HP (kW)

38 @ 2300

HYDRAULICS

Type

Open Center; Adjustable lower links with stabilizer

Total Pump Output, Main (gal. per minute)

8.71

Total Pump Output, Steering (gal. per minute)

4.62

3-Point Hitch

CAT I & II w/ Telescopic Stabilizers & Flex Links

Lift Capacity (lbs)

3748

ELECTRICAL

Battery

12 V, 925 CCA

Alternator

12 V, 55 AMP

DIMENSIONS

Overall Length [in (mm)]

136.6 (3470)

Overall Width [in (mm)]

74.8 (1900)

Overall Height [in (mm)]

60.6 (1540)

Wheelbase [in (mm)]

77.9 (1979)

Minimum Ground Clearance [in (mm)]

15.2 (385)

Turning Radius [ft (m)]

10.8 (3.29)

Weight [lb (kg)]

5390 (2445)

WHEELS & TIRES

AG [Front/Rear]

9.5 x 20 / 14.9 x 28

IND [Front/Rear]

10.5/80 x 18 / 16.9 x 24

LOADER MODEL

Model No.

5000 4L

Maximum Lift Height [in]

122

Dig Depth [in]

8.7

Dig Depth [in]

3100

Breakout Force [lbs]

3100
