ENGINE

Type

Four-stroke, Turbocharged, Direct Injection, Water Cooled Diesel Engine

Engine HP {kW} @ RPM

71 (52.9) @ 2100

Displacement [in³ (cc)]

161.7 (2650)

Number of Cylinders

3

Fuel Tank [gal (L)]

23.8 (90.0)

DRIVE TRAIN

Transmission

Full Synchro Mesh with Forward/Reverse Shuttle and Constant Mesh Range

Number of Speeds

15F/15R

Clutch

Power Shuttle with Torsonal Damper (wet)

Brakes

Oil Immersed Brakes, Disc Diameter - 8.75 in. OD (222mm) Ball and Ramp Type

PTO

Type

2-Speed Independent Single Lever PTO

Rear PTO RPM

540/540E

Mid PTO RPM

N/A

PTO HP (kW)

61 (45.5)

HYDRAULICS

Type

Open Center with Position and Draft Control, Telescoping Stabilizers and Flex Links

Implement Pump Output [gpm (L/min)]

11.1 (42.0)

Maximum Total Flow [gpm (L/min)]

15.7 (59.4)

3-Point Hitch

CAT I & II

Lift Capacity [lb (kg)]

4840 (2195)

ELECTRICAL

Battery

12 V, 925 CCA

Alternator

12 V, 140 A (Internal Fan)

DIMENSIONS

Overall Length [in (mm)]

146.9 (3731)

Overall Width [in (mm)]

82.68 (2100)

Overall Height [in (mm)]

115 (2921)

Wheelbase [in (mm)]

87.4 (2219)

Minimum Ground Clearance [in (mm)]

14.1 (358)

Turning Radius [ft (m)]

12.4 (3.7)

Weight [lb (kg)]

7495 (3399)

WHEELS & TIRES

AG [Front/Rear]

11.2 x 24 / 16.9 x 30

IND [Front/Rear]

43 x 16-20 / 18.4-28

LOADER MODEL

Standard Bucket Size [in]

78

Maximum Lift Height Width [in]

133

Dig Depth [in]

5.5

Lift Capacity to Full Height at Pivot Pin [lbs]

3550

Breakout Force [lbs]

5000

Shipping Weight [lbs]

1880
